Page 25

EN25

Menu Screen Explanations

FOCUS

AUTO

Adjusts focus automatically.





MANU

Allows you to adjust focus manually (pg. 28, 29).









EXPOSURE

AUTO

Adjusts exposure automatically.





MANU

Allows you to adjust exposure manually (pg. 27).









DATE/TIME

Allows you to set the current date and time (pg. 7).









TELE MACRO

OFF

Usually the distance to a subject where the lens is in focus







depends on the zoom magnification. Unless there is a distance





ON





more than 1m to the subject, the lens is out of focus at the













maximum telephoto setting. When set to “ON”, you can shoot a







subject as large as possible at a distance of approx. 60 cm.







•Depending on the zoom position, the lens may go out of focus.









TAPE LENGTH

Allows you to set the tape length depending on the tape used (pg. 8).









M.W.B.

AUTO

This camcorder’s Automatic Colour Temperature system senses







the colour temperature of the ambient lighting for automatic





: FINE





white balance adjustment. However, precise colour adjustment











: CLOUD

is not possible under the following conditions:







• When an object is in various shades of the same colour.





: HALOGEN





• When a predominantly red or brown object is being shot











MWB

outdoors.





In these cases, use the camcorder’s built-in preset filters for













white balance adjustment (pg. 30).









ZOOM SPEED

FAST

Allows you to set the zooming speed (pg. 14).





SLOW













= Factory setting and when the Select Dial is set to AUTO LOCK



`

CONTINUED ON NEXT PAGE
