Before Use
ªTo Use as a Hand Strap
Using the Grip Belt as the hand strap makes it easier to handle and carry a Movie Camera. It is more convenient to use with the Free Style Remote Controller with Mic.
1Detach the Grip Belt while pressing the Grip Belt Release Button (32).
(32)
2Detach the end of the Grip Belt.
3Slide A to the direction of the arrow and reattach the Grip Belt.
A
4Attach the Grip Belt around your wrist.
≥Reattach the Grip Belt to the Grip Belt Attachment until it clicks.
Attaching the Lens Cap
To protect the Lens surface, attach the Lens Cap.
1Pass the end of the Lens Cap Cord through the hole in the Grip Belt Attachment part and the Lens Cap through the Lens Cap Cord.
≥The removed Lens Cap can be hooked onto the Grip Belt. (It is not possible when using as a hand strap.)
≥When you are not recording, be sure to cover the Lens with the Lens Cap for protection.
Attaching the Shoulder Strap
We recommend that you attach the Shoulder Strap before going out of doors to record so as to avoid dropping the Movie Camera.
1Pull the end of the Shoulder Strap through the Shoulder Strap Holder (57) on the Movie
Camera.
2Fold the end of the Shoulder Strap, run it through the Shoulder Strap Length Adjuster, and pull it.
≥Pull it out more than 2 cm 1 from the Shoulder Strap Length Adjuster so that it cannot slip off.
10
