Philips 28PFL4909, 43PFL4909, 43PFL4609, 65PFL4909, 55PFL4909, 49PFL4609, 32PFL4609 Attaching the Base

Page 10

10 .English

Attaching the Base

You must attach the base to the Unit to have it as a table top Unit.

Be sure the front and rear of the base match the proper direction. For large screen TVs, at least 2 people are required for these steps.

	65PFL4909		43PFL4909 / 40PFL4909
1		1

× 4

× 3

M4 x 0.787” (20mm)

1 2

55PFL4909 / 55PFL4609 / 50PFL4909 / 49PFL4909 / 49PFL4609

1	4

× 2

M4 x 0.393” (10mm)

× 4

Continued on next page.
