JVC Model KD-S580J manual Other Main Functions, Setting the clock, To Cancel Advanced SCM

OTHER MAIN FUNCTIONS

Setting the clock

1 Press and hold SEL (Select) for more than 2 seconds.

“CLOCK H”, “CLOCK M”, “SCM LINK” or “LEVEL” appears on the display.

2 Set the hour.

1Select “CLOCK H” if not shown on the display.

2 Adjust the hour.

1 2

SSM

To Cancel Advanced SCM

You can cancel the Advanced SCM (Sound Control Memory), and unlink the sound modes and the playback sources.

When shipped from the factory, a different sound mode can be stored in memory for each source so that you can change the sound modes simply by changing the sources.

LINK ON: Advanced SCM (different SCM for different sources)

LINK OFF: Conventional SCM (one SCM for all sources)

1 Press and hold SEL for more than 2 seconds.

“CLOCK H”, “CLOCK M”, “SCM LINK” or “LEVEL” appears on the display.

ENGLISH

3 Set the minute.

1 Select “CLOCK M.”

2 Adjust the minute.

1 2

SSM

2 Select "SCM LINK" if not shown on the display.

SSM

4 Press SEL (select) to finish the setting.

To check the current clock time (changing the display mode)

Press DISP repeatedly. Each time you press the button, the display mode changes as follows.

3 Select the desire mode — "LINK ON" or "LINK OFF".

During tuner operation:

Frequency Clock

During CD operation:

Elapsed Clock playing time

4 Press SEL (select) to finish the setting.

• If the unit is not in use when you press DISP, the power turns on, the clock time is shown for 5 seconds, then the power turns off.

17
