Page 19

Detaching the control panel

You can detach the control panel when leaving the car.

When detaching or attaching the control panel, be careful not to damage the connectors on the back of the control panel and on the panel holder.

How to detach the control panel

Before detaching the control panel, be sure to turn off the power.

1 Unlock the control panel.

2 Lift and pull the control panel out of the unit.

3 Put the detached control panel into the case provided.

How to attach the control panel

1 Insert the left side of the control panel into the groove on the panel holder.

2 Press the right side of the control panel to fix it to the panel holder.

Note on cleaning the connectors:

If you frequently detach the control panel, the connectors will deteriorate.

To minimize this possibility, periodically wipe the connectors with a cotton swab or cloth moistened with alcohol, being careful not to damage the connectors.

Connectors

ENGLISH

19

Image 19
Contents KD-S580 KD-S6250For customer Use Precautions How to reset your unitInformation For USA Contents Display window Location of the ButtonsControl panel Display windowOnly for KD-S6250 This section is only for KD-S6250 Remote controllerPlace the battery Installing the batteryRemove the battery holder Return the battery holderBasic Operations Turning on the powerTo drop the volume in a moment To turn off the powerSearching a station manually Manual search Radio Basic OperationsListening to the radio Searching a station automatically Auto searchFM station automatic preset SSM When an FM stereo broadcast is hard to receiveStoring stations in memory Tune into a station of 88.3 MHz Tuning into a preset stationManual preset Select the number 1 6 for the preset station you wantInsert a disc into the loading slot CD OperationsPlaying a CD To stop play and eject the CDTo play back tracks at random Random Play Portion on a CDTo fast-forward or reverse the track To go to the next tracks or the previous tracksProhibiting CD ejection To cancel the prohibition and unlock the CDPress and hold CD and 0for more than 2 seconds Select the item you want to adjust Sound AdjustmentsAdjusting the sound Adjust the levelRecalling the sound modes Select the sound mode you wantWhen SCM Link is set to Link ON, select the source For Preset values BasRepeat the same procedure to store other sound modes Storing your own sound adjustmentTo reset to the factory settings Call up the sound mode you want to adjustTo Cancel Advanced SCM Setting the clockOther Main Functions Select Level if not shown on the display Select the desired mode VOLSelecting the level display VOL 2 or OFFHow to attach the control panel How to detach the control panelHandling CDs MaintenanceHow to handle CDs To keep CDs cleanSymptoms Causes Remedies TroubleshootingFM Tuner SpecificationsAM Tuner Call El fusible se quema Fuse blowsSound is distorted Unit becomes hotAsegúrese de conservar las manijas después de instalarlo Be sure to keep the handles after installing itNota Be sure to ground this unit to the car’s chassisRemarque Amplifier / Amplificador / Amplificateur

Model KD-S580J specifications

The JVC Model KD-S580J is a highly regarded CD receiver that combines advanced technology with user-friendly features, making it an excellent choice for car audio enthusiasts. Known for its stylish design and exceptional sound quality, this model appeals to a wide range of drivers looking to enhance their in-vehicle entertainment experience.

One of the standout features of the KD-S580J is its compatibility with various audio formats. The unit supports CD, CD-R, and CD-RW playback, allowing users to enjoy their favorite music on different disc types. It also includes an auxiliary input, making it easy to connect external devices such as smartphones or MP3 players for seamless audio streaming. For added convenience, the receiver is equipped with a USB port, enabling users to access digital music files stored on USB drives.

The KD-S580J is designed with sound quality in mind, featuring a built-in 24-bit digital-to-analog converter (DAC) that delivers clear and dynamic audio reproduction. Additionally, it offers a customizable 3-band equalizer, allowing users to adjust the bass, midrange, and treble settings to suit their personal preferences. The unit also includes various sound enhancement technologies, such as JVC's “Sound Lift” feature, which helps to elevate soundstage for a more immersive listening experience.

User-friendliness is a key characteristic of the KD-S580J. The receiver features a large, easy-to-read display that stays illuminated for optimal visibility, even in low-light conditions. The intuitive interface allows for straightforward navigation through music libraries and settings, making it accessible for users of all levels.

Furthermore, the KD-S580J supports remote control functionality, allowing users to manage playback without taking their attention off the road. Its sleek design not only enhances the aesthetic of any vehicle interior but also ensures compatibility with various dashboard styles.

In conclusion, the JVC Model KD-S580J stands out in the competitive car audio market thanks to its combination of advanced playback capabilities, sound optimization features, and user-friendly design. Its versatility and performance make it an appealing option for anyone looking to upgrade their car audio experience.
