Kenwood KDC-3454UQ, KDC-3254URY, KDC-316UR, KDC-3054URY, KDC-3354UGY, KDC-3054UG, KDC-4554U Safety

Page 3

Safety

WARNING

Stop the car before operating the unit.

Important to know...

To prevent a short circuit, never put or leave any metallic objects (such as coins or metal tools) inside the unit.

Caution: Adjust the volume so that you can hear sounds outside the car. Driving with the volume too high may cause an accident.

Condensation: When the car is air- conditioned, moisture may collect on the laser lens. This may cause disc read errors. In this case, remove the disc and wait for the moisture to evaporate.

This unit can only play the CDs with:

The illustrations in this manual are examples used to explain more clearly how the controls are used. Therefore, what appears on the illustrations may differ from what appears on the actual equipment.

A USB connection cable, CA-U1EX (max.: 500 mA) (optional accessory) is required for connecting a USB device.

You can connect an Apple iPod/iPhone

with . The word “iPod” appearing in this manual indicates the iPod or iPhone connected to this unit with a connection cable, KCA-iP102 (optional accessory).

If you experience problems during installation, consult your Kenwood dealer.

When you purchase external components, check with your Kenwood dealer to make sure that they work with your model and in your area.

Detailed information and notes about the playable audio files are stated in an online manual on the following site: www.kenwood.com/cs/ce/audiofile/

Declaration of Conformity with regard to the EMC Directive 2004/108/EC

Manufacturer:

JVC KENWOOD Corporation

3-12, Moriyacho, Kanagawa-ku, Yokohama- shi, Kanagawa, 221-0022, Japan

EU Representative’s:

Kenwood Electronics Europe BV

Amsterdamseweg 37, 1422 AC UITHOORN,

The Netherlands

This Product is not installed by the manufacturer of a vehicle on the production line, nor by the professional importer of a vehicle into an EU Member State.

The marking of products using lasers

The label is attached to the chassis/case and says that the component uses laser beams that have been classified as Class 1. It means that the unit is utilizing laser beams that are of a weaker class. There is no danger of hazardous radiation outside the unit.

For Turkey

Bu ürün 26891sayılı Resmi Gazete’de yayımlanan Elektrikli ve Elektronik Eşyalarda Bazı Zararlı Maddelerin Kullanımının Sınırlandırılmasına Dair Yönetmeliğe uygun olarak üretilmiştir.

This product complies with Directive, Number 26891 regarding “REGULATION ON THE RESTRICTION OF THE USE OF CERTAIN HAZARDOUS SUBSTANCES IN ELECTRICAL AND ELECTRONIC EQUIPMENT”.

ENGLISH

3
