Using Pan

The final Main output of the TM300 is stereo— that is, there are discrete speaker output jacks, labeled “left” and “right,” which will normally be routed to two (or two pairs of) discrete speakers. Because of this, you will usually be working with a stereo field that ranges from hard left to hard right. The TM300 provides six monophonic input channels, each with its own dedicated Pan control. The Pan circuitry in the TM300 always keeps the overall level constant, regardless of pan position. Here’s how it works: When the Pan knob is placed at its center (detented) position, signal is sent equally to both left and right outputs. When moved left of center, less signal is sent to the right output and more signal is sent to the left output (making the sound appear left of center) and when moved right of center, less signal is sent to the left output and more signal is sent to the right output (making the sound appear right of center). To route a signal hard left or right, place the pan knob either fully counterclockwise or fully clockwise.

Note that, when the TM300 is operated in a “split mono” configuration (that is, when the Aux 1 / Monitor switch is pressed in), the stereo output is internally mixed to mono and then routed to the left speaker outputs only. In this configuration, the channel Pan controls are functionally inoperative.

You can use stereo panning creatively in a variety of ways: For example, you might want to have guitars coming from one speaker and keyboards from another, or you might use panning to “spread” the signal from a piano miked with two microphones— one over the bass notes (panned left) and the other over the treble notes (panned right). By turning a Pan knob while a signal is present, the sound appears to move in space (a process known as dynamic panning)— this can be particularly effective when applied to sound effects. In live performance, you may want to resist the temptation to pan anything completely hard left or right, since some members of the audience not seated in the center of the venue may miss some signal altogether. In these circumstances, you’re best to use modest panning, with signals routed no further than the 9 o’clock and

3 o’clock positions.

L	PAN	R	ENGLISH
