Invacare Electric wheelchair manual

Page 15

Danger of injury due to wrong lifting or dropping of heavy components!

When maintaining, servicing or lifting any part of your wheelchair, take into account the weight of the individual components especially the batteries! Be sure at all times to adopt the correct lifting posture and ask for assistance if necessary!

Danger of falling out of the wheelchair.

Do not slide forward on the seat, do not lean forward between your knees, do not lean backwards out over the top of the backrest, for example to reach an object.

If restraining systems are installed (such as seat belts), use them each time you drive the wheelchair.

When changing over to a new seat, position the wheelchair as close as possible to the new seat.

Danger of injury by moving parts!

Make sure that no injury is incurred by moving parts of the wheelchair, like wheels or one of the Lifter Modules (if fitted), especially when children are around!

Danger of fire or breaking down due to electric devices being connected!

Do not connect any electric devices to your wheelchair that are not expressly certified by Invacare® for this purpose! Have all electrical installations done by your authorised Invacare® Dealer!
