Invacare Electric wheelchair manual

Page 18

Danger of breaking down in adverse weather conditions, i.e. extreme cold, in an isolated area!

If you are a user with severely limited mobility, we advise that in the case of adverse weather conditions DO NOT attempt a journey without an accompanying attendant!

Danger of injury if your foot slides off the footrest and gets caught underneath the wheelchair when it is in motion!

Make sure each time before you drive the wheelchair that your feet are squarely and securely in place on the footplates, and that both legrests are properly locked into place!

Danger of injury if you collide with an obstacle when driving through narrow passages such as doorways and entrances!

Drive through narrow passages in the lowest Driving Mode and with due caution!

18
