Handset Status



Displays relevant information regarding the Handset status.

























































Handset

Hook

SIP

DND

Forward

Busy

Delayed













Registration





Forward

Forward

























Handset 1

On Hook

Registered

Yes

613













Handset 1 is registered with SIP Server.

















Handset 1 user has set Do Not Disturb.

















Handset 1 user has set his calls to be unconditionally forwarded to ext 613.











Handset 1 user has not set Busy or Delay call Forward.



























































Core Dump



Download core dump file for troubleshooting when necessary.





























ADVANCED USER CONFIGURATION

Log in to the advanced user configuration page the same way as for the basic configuration page. The password is case sensitive and the factory default password for Advanced User is “admin”.

Advanced User configuration includes the end user configuration and the advanced configurations including: a) SIP configuration, b) Codec selection, c) NAT Traversal Setting and d) other miscellaneous configuration. DP715 has two (2) profiles for the five (5) Handsets.







Table 13:ADVANCED SETTINGS















Admin Password



This contains the password to access the Advanced Web Configuration page. This field is















case sensitive. Only the administrator can configure the “Advanced Settings” page.









Password field is purposely left blank for security reasons after clicking update and saved.









The maximum password length is 25 characters.



































Layer 3 QoS



This field defines the layer 3 QoS parameter which can be the value used for IP









Precedence or Diff-Serv or MPLS. Default value is 48.



































Layer 2 QoS



Value used for layer 2 VLAN tag. Default setting is blank.



































STUN Server



IP address or Domain name of the STUN server.



































Keep-alive interval



This parameter specifies how often the DP715 sends a blank UDP packet to the SIP









server in order to keep the “hole” on the NAT open. Default is 20 seconds. Minimum









value is 20 seconds.



































Use STUN to detect



Use STUN keep-alive to detect WAN side network problems. If keep-alive request does





network connectivity



not yield any response for configured number of times, the device will restart the TCP/IP









stack. If the STUN server does not respond when the device boots up, the feature is









disabled. Default setting is No.



































Firmware Upgrade



Enables DP715 to download firmware or configuration file through either TFTP, HTTP or





and Provisioning



HTTPS server.













Firmware version 1.0.0.23

DP715/DP710 User Manual

Page 38 of 52
