1.Data Port .....................................…...………... Convenient port to connect a computer, modem, fax or answering device.

2.Line Jack ……………………………………... Modular receptacle for connecting the line cord.

3.Headset Jack .................................…………… Convenient port for a headset connection.

4.Handset Jack ..................................………….. Connection for handset coil cord.

5. Power Adapter Receptacle ……..…………… For optional coaxial power adapter.

6.Hold Key Switch ……………...……………. Used to select standard line hold or programmable system hold.

7. Elevation Stand Lock ……………………… Used to “lock” the elevation stand..
