Spectrum Brands SP-400 manual Parts Check List

Page 14

Parts Check List

The following parts are included with the SpectrumPLUST M SP400:

1.Base Unit

2.Handset

3.Two (2) 15’ Modular telephone line cords.

4.10’ Modular coiled handset cord.

5.6” Modular wall mount line cord.

6.Power Adapter.

7.Twenty-two (22) Speed Dial Preprinted Keycaps

8.Four (4) Additional Clear Keycaps

9.Two (2) Index Sheets

(5)



(1)



(6)





(9)

P



H



O



N



E



OUT



(2)





(8)

(7)

(4)

(3)



NOTE: SpectrumPLUS TM Line Cords are 6-Pin 6-Conductor Line cords (6P6C line cord). Replacement Line Cords must be same.
