Model W1831 (For Machines Mfg. Since 2/12)

Controls and Features

Spindle	Spindle Hex Nut	Table Insert
Drum and Sanding	Spindle Washer
Sleeve
	Table
Sander Body
		Dust Port
		Drums and Sanding Sleeves
		Power
		Cord
		Table Inserts
ON/OFF Paddle Switch w/Disabling Key

Figure 1. Machine identification.

For Your Own Safety Read This Manual

Before Operating Spindle Sander

a)Wear eye protection.

b)Support workpiece on worktable.

c)Minimize pinch hazards. Use the smallest table insert possible with sanding drum.

d)Avoid kickback. Feed workpiece against rotation of drum.

e)Avoid entanglement with spinning drum. Do not wear gloves, necktie, or loose clothing. Tie back long hair.

INTRODUCTION

-5-
