| get started |
|
|
|
|
|
|
|
|
|
|
# | Name | Description | |||||||
6 | Front panel display | Shows photos remaining, battery life, | |||||||
|
|
|
|
|
|
|
|
| quality selected, share selection, and |
|
|
|
|
|
|
|
|
| storage location. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Indicates one of three storage locations: |
|
|
| Storage location | CF (Compact Flash) memory card, SD | |||||
|
|
|
|
|
|
|
|
| (Secure Digital) memory card, or PC |
|
|
|
|
|
|
|
|
| (computer hard disk). |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Indicates that the print share feature is | |||||
|
|
|
|
|
|
|
|
| enabled. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Battery life | Indicates the battery life remaining, | ||
|
|
|
|
|
| ||||
|
|
|
|
|
| ||||
|
|
|
|
|
|
|
|
| in |
|
|
|
|
|
|
|
|
| when the scanner is connected to the |
|
|
|
|
|
|
|
|
| computer. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Photos Remaining | Indicates the number of scanned photos | |||
|
|
|
|
|
|
|
|
| you can store on the memory card. This |
|
|
|
|
|
|
|
|
| number decreases each time you scan a |
|
|
|
|
|
|
|
|
| photo, and changes if you select another |
|
|
|
|
|
|
|
|
| quality setting. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Quality | Indicates the image quality (Good, |
|
|
|
|
|
|
|
| ||
|
|
|
|
|
|
|
| ||
|
|
|
|
|
|
|
| ||
|
|
|
|
|
|
|
|
| Better, Best, or Text). |
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
7 |
| Print Share button | Selects the print share feature, indicated | ||||||
|
|
|
|
|
|
|
|
| by the printer icon in the front panel |
|
|
|
|
|
|
|
|
| display. When print share is enabled a |
|
|
|
|
|
|
|
|
| DPOF file is created, along with the |
|
|
|
|
|
|
|
|
| image, to enable automated printing. |
|
|
|
|
|
|
|
|
|
|
8 | SD memory card slot | Slot where you can insert an SD memory | |||||||
|
|
|
|
|
|
|
|
| card. |
|
|
|
|
|
|
|
|
|
|
9 | CF memory card slot | Slot where you can insert a CF memory | |||||||
|
|
|
|
|
|
|
|
| card. |
|
|
|
|
|
|
|
|
|
|
10 | Indicator light | On: Scanner is ready to use. | |||||||
|
|
|
|
|
|
|
|
| Blinking light: Indicates scanner activity |
|
|
|
|
|
|
|
|
| (scanning or unloading images to the |
|
|
|
|
|
|
|
|
| computer, accessing memory card). |
|
|
|
|
|
|
|
|
|
|
11 | USB port | Allows you to connect a USB cable from | |||||||
|
|
|
|
|
|
|
|
| the scanner to a |
|
|
|
|
|
|
|
|
|
|
12 | Lid | Removable lid of the scanner. | |||||||
|
|
|
|
|
|
|
|
|
|
user’s manual | 9 |
