Page 15

Right side

Component



Description







(1)

Audio-out (headphone) jack/Audio-in

Connects optional powered stereo speakers, headphones,



(microphone) jack

earbuds, a headset, or a television audio cable. Also





connects an optional headset microphone. This jack does





not support optional microphone-only devices.





WARNING! To reduce the risk of personal injury, adjust





the volume before putting on headphones, earbuds, or a





headset. For additional safety information, refer to the





Regulatory, Safety, and Environmental Notices. To access





this guide, from the Start screen, type support, select the





HP Support Assistant app, select My computer, and then





select User guides.





NOTE: When a device is connected to the jack, the





computer speakers are disabled.





NOTE: Be sure that the device cable has a 4-conductor





connector that supports both audio-out (headphone) and





audio-in (microphone).







(2)

USB 3.0 ports (2)

Connect optional USB devices.





NOTE: For details about different types of USB ports, see





Using a USB device on page 46







(3)

HDMI port

Connects an optional video or audio device, such as a high-





definition television, any compatible digital or audio





component, or a high-speed HDMI device.







(4)

RJ-45 (network) jack

Connects a network cable.







(5)

AC adapter light

White: The AC adapter is connected and the battery is





charged.





Amber: The AC adapter is connected and the battery





is charging.





Off: The computer is using battery power.







(6)

Power connector

Connects an AC adapter.







Right side

5
