HP LV1561w, LV1561WS, CQ1569 Operating the Monitor, Installing the Driver, Installing from the CD

Page 16

4 Operating the Monitor

Installing the Driver

You can install the monitor-driver INF and ICM files from the CD (included with select models) or download from the Internet.

Installing from the CD

To install the .INF and .ICM files on the computer from the CD:

1.Insert the CD in the computer CD-ROM drive. The CD menu is displayed.

2.Select the language.

3.View the Monitor Driver Software Readme file.

4.Select Install Monitor Driver Software.

5.Follow the on-screen instructions.

6.Ensure that the proper resolution and refresh rates appear in the Windows Display control panel.

NOTE: You may need to install the digitally signed monitor .INF and .ICM files manually from the CD in the event of an installation error. Refer to the Monitor Driver Software Readme file on the CD.

Downloading from the Worldwide Web

To download the latest version of .INF and .ICM files from the HP monitors support Web site:

1.Refer to http://www.hp.com/support and select the country region.

2.Select Download Drivers and Software.

3.Enter the model number of the monitor. The software download pages for the monitor are displayed.

4.Ensure the system meets the requirements.

5.Download the software by following the instructions.

10 Chapter 4 Operating the Monitor

ENWW
