HP L1510 15” LCD Monitor

Adjusting Your Monitor

Automatic Setup

Using the Auto button and the test pattern on the CD-ROM provided, you can easily optimize your screen performance.

1Insert the CD-ROM provided into the PC. Run the program D:\auto.exe to display a pattern used for setup.

2Press the Auto button. Normally, this should produce a stable, centered image.

Your optimizer utility also contains driver for Windows 95, Windows 98 or Windows 2000 D:\Drivers\D5062A.INF.

Manual Setup

Follow these steps only if further adjustments are needed. For further information, refer to “Using Your Monitor” on page 12 .

1Display the pattern using the CD-ROM as described above.

2Press Enter to display the OSD menu.

3Select the Geometry icon.

4Select Pixel Clock and adjust the value to minimize vertical bars.

5Select Phase and adjust the value to minimize horizontal bars.

6 Select Horizontal Position and

Vertical Position

to adjust screen position.



7Press the Exit button to save the values.

English 11
