HP L1510 15” LCD Monitor

Using Your Monitor

The Sub-Menus

Luminance

Contrast adjusts the difference between the light and dark areas.

Brightness adjusts the brightness of the display.

To make adjustments in the Luminance sub-menu:

1Press the Menu button and use the or buttons to highlight the Luminance icon.

2Press the button to select the feature.

3Use the or buttons to choose either Contrast or

Brightness, then press to select it.

4Press or buttons to adjust the settings (the settings are automatically saved).

5Press the Menu button to exit the sub-menu, then press the Menu button to exit the respective sub-menus

6Press the Menu button to exit the OSD.

14 English
