hp pavilion f50/f70 LCD Monitor Using the Monitor

Setting Options

The icons at the top of the Display Manager window represent the different setting options, shown in the following table:

Icon	Setting option	Setting description
	Horizontal	Adjusts the horizontal position of the screen
	Position*	image.
	Vertical	Adjusts the vertical position of the screen
	Position*	image.
	Clock*	Adjusts the frequency of the pixel clock to
		minimize vertical bars.
	Phase*	Adjusts the phase value to minimize
		horizontal bars.
	Auto Config*	Adjusts the main settings and produces a
		stable, centered image.
	Color	Adjusts the tint of white, and the red, green,
		and blue (RGB) mix for colors.
	Contrast	Adjusts the difference between the light and
		dark areas.
	Brightness	Adjusts the brightness.
	OSD Manager	Adjusts the position, timeout, and notification
	(OSD stands for	features of the Display Manager window.
	onscreen
	display)
	Mode Recall	Resets the display to original factory settings
		for color, brightness, phase, and clock.
	Backlight Info	Shows the status of the light behind the
		panel.
	Serial Number	Shows the serial number of the display.
	Mode Info	Shows the current resolution and refresh rate;
		shows if you’re in analog or digital mode;
		and shows how many user settings have
		been adjusted.
	Input Priority	Sets which video input is active: analog or
		digital. Shows status of the video input that is
		active.
	Languages	Shows the language of the OSD window.

X25
