getting to know the camcorder

WHAT'S INCLUDED WITH YOUR CAMCORDER

Your new camcorder comes with the following accessories. If any of these items are missing from your box, call Samsung’s Customer Care Centre.

Model name Colour Memory card slot

LCD screen

Lens

MENU

	HMX-E10WP	White
	HMX-E15WP	White
	HMX-E15WP

	HMX-E10BP	Black
	HMX-E15BP	Black
	HMX-E15BP

	HMX-E10OP	Orange
	HMX-E15OP	Orange
	HMX-E15OP

Yes

Colour

Digital zoom: x2

•The shape is the same for all models. Only the colour is different.

Checking your accessories

Battery

Hand strapUser manual CD

(BP90A)

Optional accessories

Quick start guide	Mini HDMI cable	Pouch	Memory card

•The contents may vary depending on the sales region.

•Parts and accessories can be purchased after consulting with your local Samsung dealer. SAMSUNG is not responsible for reduced built-in battery life time or malfunctions caused by any unauthorised use of accessories such as the battery.

•A memory card is not included. See page 28 for memory cards compatible with your camcorder.

10• Your camcorder includes the user manual CD and printed quick start guide.
