search and play

BEFORE USE

Search
Calendar
Event
Date/Time
Go to First
Go to Last
Backup
Move/Control	Select	Exit

When you press the SEARCH button, the Search window appears after user validation checkup. Available menus are like the following:

Calendar: Searches the recorded video images using the calendar to select the wanted time.

Event: Searches the recorded video images using events.

Date/Time: Searches the recorded video images using the input date and time.

Go To First: Searches the first recorded video image.

Go To Last: Searches the latest video image.

Backup: Searches the backup video images. It searches the images recorded on the USB HDD or USB memory. The AVI format backup files recorded on USB CD/DVD or built-in CD can be played on PC.

CALENDAR SEARCH

You can search the recorded video images using the calendar as shown in the picture.

Calendar
Sun	Mon	Tue	Wed	Thu	Fri	Sat
					OK	Cancel

In case of SHR-5082, only 8 channels are displayed.

To perform a calendar search

1.Use the Direction buttons to select each channel, then press the ENTER button.

If you press CH >, all channels are selected.

2.Use the Direction buttons and ENTER button to select the wanted year and month. If any recordings are stored for the selected month, the corresponding dates are highlighted in the calendar.

If you press or , the year value changes.

3.Use the Direction buttons and ENTER button to mark the wanted dates.

4.Use the DOWN direction button to move to the time bar, and use the LEFT and RIGHT direction buttons to place the cursor to the wanted time block. Then press the ENTER button for selection.

The scales of time bar are displayed at 30 minutes each.

5.Press OK to search the wanted image data.

If the selected time block has no images, the system displays no picture.

EVENT SEARCH

This function searches recorded results such as normal recording, schedule recording, alarm recording, motion recording, and video loss recording on the channel and time basis.

Event Search (Can Select 1 Event)
No.		Date/Time		Event Mode
First	Prev	Next	Last	Start	Cancel

In case of SHR-5082, only 8 channels are displayed.

40_ search & play
