GAS Requirements

installing your dryer

Use only natural or LP (liquid propane) gases.

THE INSTALLATION MUST CONFORM WITH LOCAL CODES, OR IN THE ABSENCE OF LOCAL CODES, WITH THE NATIONAL FUEL GAS CODE ANSI/Z223.1, LATEST REVISION (FOR THE UNITED STATES), OR WITH THE CAN/CGA-B149 INSTALLATION CODES (FOR CANADA).

Gas dryers are equipped with a burner vent for use with natural gas. If you plan to use your dryer with LP (liquid propane) gas, it must be converted for safe and proper performance by a qualified service technician. A 1/2” (1.27 cm) gas supply line is recommended and must be reduced to connect to the 3/8” (1 cm) gas line on your dryer. The National Fuel Gas Code requires that an accessible, approved manual gas shut-off valve be installed within 6” of your dryer.

Gas dryers installed in residential garages must be raised 18 inches (46 cm) above the floor.

Additionally, a 1/8” (0.3 cm) N.P.T. (National Pipe Thread) plugged tapping, accessible for test gauge connection, must be installed immediately upstream of your dryer’s gas supply connection.

Your dryer must be disconnected from the gas supply pipe system during any pressure testing of the system.

DO NOT reuse old flexible metal gas lines. Flexible gas lines must be design certified by the American Gas Association (CGA in Canada).

•Any pipe joint compound used must be resistant to the action of any liquefied petroleum gas.

•As a courtesy, most local gas utilities will inspect a gas appliance installation.

GAS IGNITION – Your dryer uses an automatic ignition system to ignite the burner. There is no constant burning pilot.

COMMONWEALTH OF MASSACHUSETTS INSTALLATION INSTRUCTIONS

Your dryer must be installed by a licensed plumber or gas fitter. A “T” handle manual gas valve must be installed in the gas supply line to your dryer. If a flexible gas connector is used to install your dryer, the connector must have a maximum length of 3’ (36”).

•Gas leaks may occur in your system, creating a dangerous situation. WARNING • Gas leaks may not be detected by smell alone.

•Gas suppliers recommend you purchase and install a UL-approved gas detector.

•Install and use in accordance with manufacturer’s instructions.

14_ installing your dryer

DV520AE-02836B-01_EN.indd Sec2:14

2011-10-05 1:59:14

DV520AEP/XAA specifications

The Samsung DV520AEP/XAA is a sophisticated and versatile dryer designed to meet the demands of modern households while ensuring efficiency, reliability, and convenience. Known for its advanced features and cutting-edge technology, this dryer is a popular choice for those seeking optimal performance and energy savings.

One of the standout features of the Samsung DV520AEP/XAA is its large capacity, which can accommodate up to 7.5 cubic feet of laundry. This ample space allows users to dry larger loads in one go, minimizing the number of drying cycles needed and significantly enhancing efficiency. The dryer also incorporates Samsung's Multi-Steam technology, which not only dries clothes effectively but also helps to reduce wrinkles and odors. This feature is particularly beneficial for busy households, as it ensures that garments come out looking fresh and ready to wear without the need for extensive ironing.

Energy efficiency is a hallmark of the DV520AEP/XAA, as it boasts an Energy Star certification. This means that it meets or exceeds energy efficiency standards, allowing customers to save on utility bills while reducing their carbon footprint. Additionally, the dryer comes equipped with a sensor dry system that intelligently detects moisture levels in the fabric and adjusts drying times accordingly. This provides optimal drying results while preventing over-drying, which can lead to wear and tear on fabrics.

The user-friendly interface of the Samsung DV520AEP/XAA includes a variety of drying cycles and options tailored to different fabric types and user preferences. From delicate cycles for gentle care to heavy-duty settings for bulky items, the dryer accommodates diverse laundry needs. Moreover, the drum is designed with a stainless steel finish that prevents snagging and helps maintain the integrity of clothes over time.

Samsung has also prioritized smart technology in this model. The Smart Care feature allows users to troubleshoot issues directly from their smartphones, providing convenience and peace of mind. By connecting the dryer to a home Wi-Fi network, users can monitor and control settings remotely.

In conclusion, the Samsung DV520AEP/XAA is an innovative dryer that combines efficiency, advanced technology, and user-friendly features. From its large capacity and energy-saving capabilities to smart connectivity, this model stands out as an exceptional appliance for modern laundry needs. With its focus on performance and convenience, it is an ideal choice for busy families looking for reliable and effective laundry solutions.
