Samsung LS19HJBQHV/SAI, LS17HJBQHV/SAI, LS17HJBQHV/XSG manual Color Tab Definition

Page 29

Resolution Lists all display resolutions supported by the program.

MagicBright™ is a new feature providing the optimum viewing environment depending on the contents of the image you are watching. Currently four different modes are available: Text, Internet,Game, Sport, Movie and Custom. Each mode has its own pre-configured brightness value. You can easily select one of six settings by simply pressing MagicBright control buttons.

1.Text: For documentations or works involving heavy text.

2.Internet: For working with a mixture of images such as text and graphics.

3.Game : For watching motion pictures such as a Game.

4.Sport : For watching motion pictures such as a Sport.

MagicBright™ 5. Movie: For watching motion pictures such as a DVD or Video CD.

6.Custom: Although the values are carefully chosen by our engineers, the pre-configured values may not be comfortable to your eyes depending on your taste. If this is the case, adjust the Brightness and Contrast by using the OSD menu.

MagicBright control mode will be different according to monitor models.

Some monitor will only support Four modes(Text, Internet, Entertain, Custom)

Color Tab Definition

Adjusts the "warmth" of the monitor background or image color.

MagicColor and Gamma will be shown only in the monitor that supports these functions.

Color Tone Color Control Calibration MagicColor Gamma

The tone of the color can be changed.

Image 29
