Page 32

Image Setup Position Sharpness



z

Fine : Removes noise such as horizontal stripes.





If the noise persists even after Fine tuning, repeat it after adjusting the





frequency (clock speed).

Image Setup

z

Coarse : Removes noise such as vertical stripes.



Coarse adjustment may move the screen image area.









You may relocate it to the center using the Horizontal Control menu.



z

Auto Setup : Auto adjustment allows the monitor to self-adjust to the





incoming video signal. The values of fine, coarse and position are adjusted





automatically.

Position

Adjusts the screen location horizontally and vertically.





Sharpness

Changes the clearance of image.







Option Tab Definition

You can configure MagicTune™ using the following options.

Loads the Preferences Dialog Box. Preferences in use will have an "V" in the check box. To turn on or off any Preference, position the cursor over the box and click.

Preferences

z

Enable task tray menu .



- To access the MagicTune™ menus, click the icon on the [task tray









menu].





The menus are not displayed if the [Enable System Tray] is deselected in





[Options] ' [Basic Settings].



z

Select Language - The language chosen affects only the language of the





OSD.

Source Select

z

Analog



z

Digital

Image 32
