Broiling and Custom Broiling

BROILER

The broiler is located below the oven door. The broiler pan and grid roll out for easy access. Always broil with the broiler drawer and oven door closed.

To avoid damage to the broiler, do not step on or apply weight to the broiler door while it is open.

Do not preheat broiler before use. Completely close broiler drawer during broiling.

Do not use broiler drawer for storage.

Use only the broiler pan and grid. It is designed to drain juices and help avoid spatter and smoke.

For proper draining, do not cover the grid with foil. The bottom of the pan may be lined with aluminum foil for easier cleaning.

Trim excess fat to reduce spattering. Slit the remaining fat on the edges to avoid curling.

Use tongs to turn food to avoid the loss of juices. Very thin cuts of fish, poultry or meat may not need to be turned.

After broiling, remove the pan from the oven when removing the food. Drippings will bake on the pan if left in the heated oven, making cleaning more difficult.

To Broil:

1.Open the broiler door and roll out the broiler pan and grid.

2.Place the broiler pan and grid so grease can drain down into the lower part of the broiler pan.

3.Place food on broiler pan. Then place the pan on the broiler rack and close the door.

4.Press CUSTOM BROIL.

The BROIL indicator light will light up.

5.Press START.

The On and Temp indicator lights will light up. The temperature setting can be changed at any time during broiling. If broiling while the Timer is counting down, the set broiling temperature can be displayed for 5 seconds by pressing CUSTOM BROIL.

6.Press CANCEL when finished broiling.

To Custom Broil:

Changing the temperature while custom broiling allows more precise control when cooking. The lower the temperature, the slower the cooking. Thicker cuts and unevenly shaped pieces of meat, fish and poultry may cook better at lower broiling temperatures. If food is cooking too quickly, the broiling temperature can be lowered by touching the TEMP/TIME “-” pad.

1.Press CUSTOM BROIL.

2.Press the TEMP/TIME “+” or “-” pads to set a temperature between 300°F (149°C) and 525°F (273°C).

3.Press START.

4.Press CANCEL when finished broiling.

Positioning Broiler Pan

For models with a broiler drawer:

1.Make sure the oven is off and cool.

2.Hold each side of the broiler pan and set it at the desired position on top of the supports at each corner. Depending on the position desired, it may be necessary to tilt the broiler pan.

A B

A. Broiler pan

B. Supports (4)

3.To remove the broiler pan, tilt the broiler pan and lift it out from between the supports.

BROILING CHART

For best results, place food 3" (7 cm) or more from the broil element. Times are guidelines only and may need to be adjusted for individual foods and tastes.



COOK TIME

FOOD

Minutes

SIDE 1

SIDE 2









Chicken pieces, bone-in

15-17

15-17

Chicken breasts, boneless

11-13

11-13







Fish Fillets ¹₂ - ³₄ " (1.25-1.8 cm) thick

7-8

3-4







Frankfurters

5-6

2-3







Ground meat patties ³₄ " (1.8 cm) thick,





well-done*

11-13

6-7







Ham slice, precooked ¹₂ " (1.25 cm)





thick

6-8

3-4







Lamb chops 1" (2.5 cm) thick

14-17

8-9







Pork chops 1" (2.5 cm) thick

19-21

9-10







Steak 1" (2.5 cm) thick, medium rare,

10-12

5-6

medium

12-14

6-7

well-done

16-17

8-9







*Place up to 9 patties, equally spaced, on broiler grid.

11
