Maytag W10366207A, MFF2558VEM installation instructions Temperature and Moisture, Ice and Water

Page 17

■Sizzling/Gurgling - water dripping on the heater during defrost cycle

■Popping - contraction/expansion of inside walls, especially during initial cool-down

■Water running - may be heard when ice melts during the defrost cycle and water runs into the drain pan

■Creaking/Cracking - occurs as ice is being ejected from the ice maker mold.

The doors will not close completely

■Door blocked open? Move food packages away from door.

■Bin or shelf in the way? Push bin or shelf back in the correct position.

The doors are difficult to open

WARNING

Explosion Hazard

Use nonflammable cleaner.

Failure to do so can result in death, explosion, or fire.

■Gaskets dirty or sticky? Clean gaskets and contact surfaces with mild soap and warm water. Rinse and dry with soft cloth.

Temperature and Moisture

Temperature is too warm

■New installation? Allow 24 hours following installation for the refrigerator to cool completely.

■Door(s) opened often or left open? Allows warm air to enter refrigerator. Minimize door openings and keep doors fully closed.

■Large load of food added? Allow several hours for refrigerator to return to normal temperature.

■Controls set correctly for the surrounding conditions? Adjust the controls a setting colder. Check temperature in 24 hours. See “Using the Control(s).”

Ice and Water

The ice maker is not producing ice or not enough ice

■Refrigerator connected to a water supply and the supply shutoff valve turned on? Connect refrigerator to water supply and turn water shutoff valve fully open.

■Kink in the water source line? A kink in the line can reduce water flow. Straighten the water source line.

■Ice maker turned on? Make sure wire shutoff arm or switch (depending on model) is in the ON position.

■New installation? Wait 24 hours after ice maker installation for ice production to begin. Wait 72 hours for full ice production.

■Freezer door closed completely? Firmly close the freezer compartment door. If the freezer compartment door will not close all the way, see “The doors will not close completely,” earlier in this section.

■Large amount of ice recently removed? Allow 24 hours for ice maker to produce more ice.

■Ice cube jammed in the ice maker ejector arm? Remove ice from the ejector arm with a plastic utensil.

■Water filter installed on the refrigerator? Remove filter and operate ice maker. If ice volume improves, then the filter may be clogged or incorrectly installed. Replace filter or reinstall it correctly.

■Reverse osmosis water filtration system connected to your cold water supply? This can decrease water pressure. See “Water Supply Requirements.”

The ice cubes are hollow or small

NOTE: This is an indication of low water pressure.

■Water shutoff valve not fully open? Turn the water shutoff valve fully open.

■Kink in the water source line? A kink in the line can reduce water flow. Straighten the water source line.

■Water filter installed on the refrigerator? Remove filter and operate ice maker. If ice quality improves, then the filter may be clogged or incorrectly installed. Replace filter or reinstall it correctly.

■Reverse osmosis water filtration system connected to your cold water supply? This can decrease water pressure. See “Water Supply Requirements.”

■Questions remain regarding water pressure? Call a licensed, qualified plumber.

There is interior moisture buildup

NOTE: Some moisture buildup is normal.

■Humid room? Contributes to moisture buildup.

■Door(s) opened often or left open? Allows humid air to enter refrigerator. Minimize door openings and keep doors fully closed.

Off-taste, odor or gray color in the ice

■New plumbing connections? New plumbing connections can cause discolored or off-flavored ice.

■Ice stored too long? Discard ice. Wash ice bin. Allow 24 hours for ice maker to make new ice.

■Odor transfer from food? Use airtight, moisture proof packaging to store food.

17

Page 16 Page 18
Image 17
Page 16 Page 18
Contents Refrigerator User Instructions Refrigerator SafetyUnpack the Refrigerator Installation InstructionsBefore You Throw Away Your Old Refrigerator or Freezer Remove the PackagingLocation Requirements Clean Before UsingElectrical Requirements Recommended Grounding MethodConnect the Water Supply Water Supply RequirementsWater Pressure Reverse Osmosis Water SupplyStyle Complete the InstallationConnect to Refrigerator Remove and Replace Refrigerator Door Handles Standard Door Refrigerator Doors and DrawerFrench Doors Remove Door and Hinges Standard DoorReplace Door and Hinges Standard Door Reverse Door Standard Door optionalCabinet Refrigerator doorRemove and Replace Drawer Handle Remove and Replace Freezer DrawerRemove Drawer Front Replace Drawer FrontStandard Door Door Removal Replacement Door Swing Reversal optionalDrawer Front Removal Drawer Front Replacement Opening and Closing Doors Refrigerator USEDoor Closing and Door Alignment Digital Controls Using the ControlsElectronic Controls Additional Digital Control Center Features Fast Cool To Adjust Set Point TemperaturesDoor Alarm Reset FilterWater Dispenser Crisper Humidity ControlIce Maker Water Filtration System CleaningRefrigerator Care Refrigerator Operation TroubleshootingChanging the Light Bulb Ice and Water Temperature and MoistureWater dispenser will not operate properly Water Filter CertificationsWater is leaking from the dispenser system Water from the dispenser is warmApplication Guidelines/Water Supply Parameters Performance Data SheetsModel UKF8001AXX-200 Capacity 200 Gallons 757 Liters Limited Warranty Maytag Major Appliance WarrantyItems Excluded from Warranty This limited warranty does not coverSeguridad DEL Refrigerador Instrucciones Para EL Usuario DEL RefrigeradorDesempaque el refrigerador Instrucciones DE InstalaciónAntes de tirar su viejo refrigerador o congelador Cómo quitar los materiales de empaqueMétodo de conexión a tierra recomendado Requisitos de ubicaciónRequisitos eléctricos Conexión del suministro de agua Requisitos del suministro de aguaPresión del agua Suministro de agua por ósmosis inversaComplete la instalación Conexión al refrigeradorEstilo Cómo quitar la puerta y las bisagras Puerta estándar Puertas y cajón del refrigeradorDos puertas con congelador en la parte inferior Puerta del congelador CarcasaPuerta del refrigerador Cómo quitar y volver a colocar el cajón del congelador Dos puertas con congelador en la parte inferorCómo quitar y volver a colocar la manija del cajón Para quitar el frente del cajónPuerta estándar Cambio del sentido de apertura de las puertas opcionalDos puertas con congelador en la parte inferior Bisagras superioresCierre y alineamiento de la puerta Cómo abrir y cerrar las puertas USO DE SU RefrigeradorUso de los controles Controles electrónicosControles digitales Fábrica de hielo Sistema de filtración de agua Despachador de aguaLimpieza Cuidado DE SU RefrigeradorCómo cambiar el foco Reemplazo del filtro de aguaFuncionamiento del refrigerador Solución DE ProblemasHielo y agua Temperatura y humedad¿Está la presión de agua a por lo menos 35 lbs/pulg² El agua del despachador está tibiaPautas de aplicación/Parámetros para el suministro de agua Hoja DE Datos DEL RendimientoModelo UKF8001AXX-200 Capacidad 200 galones 757 litros Garantía Limitada MaytagExclusiones DE LA Garantía Esta garantía limitada no cubreMaytag Brand Home Appliances Sécurité DU Réfrigérateur Instructions Dutilisation DU RéfrigérateurDéballage du réfrigérateur Instructions D’INSTALLATIONAvant de jeter votre vieux réfrigérateur ou congélateur Enlèvement des matériaux d’emballageSpécifications électriques Exigences demplacementMéthode recommandée de mise à la terre Pression de leau Raccordement de la canalisation deauAlimentation en eau par osmose inverse Raccordement à une canalisation d’eauRaccordement au réfrigérateur Achever l’installationDépose des portes et des charnières Porte standard Portes et tiroir du réfrigérateurPorte à deux battants Caisse Réinstallation Porte et charnières Porte standardPorte du compartiment de réfrigération Porte du compartiment de congélationDépose et réinstallation de la poignée du tiroir Retirer et réinstaller le tiroir du congélateurRéinstallation de la façade du tiroir Portes à deux battantsPorte standard Inversion du sens douverture de la porte facultatifPortes à deux battants Charnières supérieuresFermeture et alignement de la porte Commandes électroniques Utilisation des commandesUtilisation DU Réfrigérateur Ouverture et fermeture des portesAjustement des réglages de commande Commandes numériquesAjustement des réglages de commande numérique Pour ajuster les points de réglage de températureDoor Alarm avertisseur de la porte Temp Alarm alarme de dépassement de températureReset Filter réinitialisation du filtre Préférences de lutilisateur avec la commande numériqueDistributeur d’eau Machine à glaçonsMise en marche/arrêt de la machine à glaçons Taux de production des glaçonsNettoyage Entretien DU RéfrigérateurSystème de filtration de leau Fonctionnement du réfrigérateur Remplacement de l’ampoule d’éclairageDépannage Glaçons et eau Température et humiditéMauvais goût, odeur ou couleur grise des glaçons Les glaçons sont creux ou petitsLe distributeur deau ne fonctionne pas correctement ’eau coule du système de distributionSystème de filtration d’eau intérieur Feuilles DE Données SUR LA PerformanceModèle UKF8001AXX-200 /Capacité 200 gallons 757 litres Garantie Limitée Garantie DE Gros Appareil Ménager MaytagÉléments Exclus DE LA Garantie La présente garantie limitée ne couvre pasPage EN/FR PN W10366206A W10366207A

W10366207A, MFF2558VEM specifications

The Maytag MFF2558VEM is a sophisticated and reliable refrigerator designed to cater to the modern user's needs. It combines functionality and style, making it a perfect addition to any kitchen. This model comes with a host of features that enhance its usability and performance, making it stand out in its class.

One of the main attributes of the Maytag MFF2558VEM is its spacious interior. With a total capacity of 25 cubic feet, there's plenty of room for groceries, beverages, and storage containers. The refrigerator layout is thoughtfully designed, offering adjustable shelves and a crisper drawer that helps keep fruits and vegetables fresher for longer. The humidity-controlled crisper drawers ensure optimal conditions for your produce, preventing spoilage and maintaining freshness.

The refrigerator boasts an advanced cooling system that employs precise temperature control technology. This feature allows users to customize and maintain their desired temperature settings throughout the refrigerator and freezer compartments, ensuring food remains at the ideal temperature. The EvenTemp cooling system circulates cool air throughout the unit, eliminating hot spots and ensuring consistent cooling.

Another significant feature is the water and ice dispenser, which is conveniently located on the exterior door. This provides easy access to filtered water and cubed or crushed ice, making it effortless to stay hydrated or prepare meals. The filtration system ensures that the water supplied is clean and refreshing, crucial for health-conscious consumers.

Energy efficiency is another hallmark of the Maytag MFF2558VEM. It is ENERGY STAR certified, meaning it meets strict guidelines for energy consumption. This reduces environmental impact while saving on utility bills, making it an eco-friendly choice.

The stainless steel finish not only gives the refrigerator a sleek look but is also smudge-resistant, ensuring it maintains its aesthetic appeal with minimal effort. The strong build quality of Maytag products ensures durability and performance reliability, making this model a long-term investment.

In addition to its practical features, the Maytag MFF2558VEM includes a 10-year limited parts warranty on the compressor, providing peace of mind for users concerned about potential repairs. Overall, this refrigerator embodies a blend of technology, convenience, and efficiency, making it an ideal partner in any busy kitchen. With its robust set of features and durable construction, it promises to deliver excellent refrigeration performance for years to come.
