Liebherr CS 1611 7801 149-00 manual Operating and Control Elements , Figure, Appliance

Page 7

Features

Operating and Control Elements - Figure 2, Figure 3

The electronic control panel has the new “Touch capacitance technology”. Any function can be activated by a fingertip on the symbol of the operating icons.

The exact contact point is between the symbol and its label



Refrigerator



Appliance



operating icons

control icons































































































































































Figure 2

Refrigerator operating icons











Appliance control icons

Ventilation (circulation) On/











Power failure LED





Off











Supercooling LED

Supercool































Refrigerator On/Off











Child lock LED













Temperature Up control (to











Alarm LED













increase the refrigerator











Icemaker ON LED

temperature)























Temperature Down control











Superfrost LED











(to reduce the refrigerator











Ventilation ON LED

temperature)























Freezer

operating icons

Freezer operating icons

Temperature Up control (to increase the freezer tem- perature)

Temperature Down control (to reduce the freezer tem- perature)

Freezer On/Off

Superfrost

Alarm mute (refrigerator and freezer)

Temperature and control display



Display mode degrees Celsius



Refrigerator temperature display

Sabbath mode is activated



Menu mode is activated

Freezer temperature display



(for setting additional functions)





Display mode degrees Fahrenheit



Figure 3

7
