Kenmore 318205342A manual Care and Cleaning of Stainless Steel Some models, To Remove Oven Door

Page 31

General Care & Cleaning

Door Hinge locations with oven door fully open

Fig. 1

Care and Cleaning of Stainless Steel (Some models)

Some models are equipped with stainless steel exterior parts. Special care and cleaning are required for maintaining the appearance of stainless parts. Please refer to the table provided at the beginning of the General Care & Cleaning section in this Use & Care Guide.

Removing and Replacing the Lift-Off Oven Door

CAUTION The door is heavy. For safe, temporary storage, lay the door flat with the inside of the door facing down.

To Remove Oven Door:

1.Open oven door completely (horizontal with floor - See Fig. 1).

2.Pull the door hinge locks on both left and right door hinges down from the oven frame completely towards the oven door (See Fig. 2). A tool such as a small flat-blade screwdriver may be required.

3.Firmly grasp both sides of oven door along the door sides (Do not use the oven door handle - See Fig. 3).

4.Close the door to about a 10 degree angle as shown in Fig. 3.

5.With the oven door in this position, lift the oven door hinge arms away from

Fig. 2

the roller pins located on each side of the oven frame (See Fig. 4).

10°

Oven door

Hinge

Fig. 3

Roller pin

Hinge arm hook

Fig. 4

To Replace Oven Door:

1.Firmly grasp both sides of oven door along the door sides (Do not use the oven door handle - See Fig. 3).

2.Holding the oven door at the same angle as the removal position, seat the hook of the hinge arm onto the roller pins located on each side of the oven door frame (See Fig. 4). The hook of the hinge arms must be fully seated onto the roller pins.

3.Fully open the oven door (horizontal with floor - See Fig. 1).

4.Push the door hinge locks up towards and into the oven frame on both left and right oven door hinges (See Fig. 2) to the locked position.

5.Close the oven door.

Special Door Care Instructions - Most oven doors contain glass that can break. Read the following recommendations:

1.Do not close the oven door until all the oven racks are fully in place.

2.Do not hit the glass with pots, pans, or any other object.

3.Scratching, hitting, jarring or stressing the glass may weaken its structure causing an increased risk of breakage at a later time.

31
