C H A P T E R
5 Specifications
Table 6—Specifications
Parameter | Specification |
Physical | Height - 1.3" |
| Width - 3.9" |
| Depth - 5.7" |
| Weight - 1.0 lb. |
|
|
Environment | Complies with AT&T Pub. 62310. |
Operating temperature | 0°C to 60°C (32 °F to 140°F) |
Storage temperature | |
Relative humidity | 0% to 95% noncondensing |
|
|
Power | +7.5 VDC with 1W dissipation |
| Provides automatic lightning and surge |
| protection for the S/T and U interfaces |
Power adapter option | Provides power to the NT1 only |
|
|
Network Interface | Automatic ANSI maintenance functions |
Line | |
Data rate | 144 kbps available to customer |
Line code | 2B1Q per ANSI T1.601, 1992 |
O/P amplitude | 2.5V, |
Connector | One RJ45 or one RJ11 |
|
|
15
