Energy Star 4.0c Support [Disabled]

Setting this item to [Enabled] to pass Energy Star 4.0c rating. When enabled,

S3-PS/2 & USB wake-up functions will be closed, and S4/S5-Marvell LAN, PS/2 & USB devices wake-up functions will be closed.

Configuration options: [Enabled] [Disabled]

3.6.6

Hardware Monitor

CPU Temperature





BIOS SETUP UTILITY











Power







Hardware Monitor











CPU Temperature

[47ºC/116.5ºF]





MB Temperature

[32ºC/89.5ºF]





CPU Fan Speed

[4500RPM]





CPU Q-Fan Control

[Disabled]





Chassis Fan 1 Speed

[N/A]





Chassis Fan 2 Speed

[N/A]



Select Screen

Chassis Q-Fan Control

[Disabled]



+-

Select Item

Power Fan Speed

[N/A]

Change Field

F1

General Help











CPU

Voltage

[ 1.304V]

F10

Save and Exit

ESC

Exit

3.3V

Voltage

[ 3.248V]





5V

Voltage

[ 5.112V]





12V

Voltage

[12.096V]





v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.

CPU Temperature [xxxºC/xxxºF]

MB Temperature [xxxºC/xxxºF]

The onboard hardware monitor automatically detects and displays the motherboard and CPU temperatures. Select [Ignored] if you do not wish to display the detected temperatures.

CPU Fan Speed [xxxxRPM] or [Ignored] / [N/A]

The onboard hardware monitor automatically detects and displays the CPU fan speed in rotations per minute (RPM). If the fan is not connected to the motherboard, the field shows [N/A].

CPU Q-Fan Control [Disabled]

Allows you to enable or disable the CPU Q-fan control feature. Configuration options: [Disabled] [Enabled]

3-34

Chapter 3: BIOS setup
