Technical Specifications

NOTE: Offerings may vary by region. For more information regarding the configuration of your computer, click Start (Start icon) Help and Support, and then select the option to view information about your computer.

NOTE: In Windows 8, navigate to Help and Support to view information about your computer.

Table 16. System Information

Feature

Specification





Chipset

Mobile Intel QM87 Express chipset

DRAM bus width

64-bit

Flash EPROM

SPI 32 Mbits, 64 Mbits

PCIe bus

100 MHz

External Bus Frequency

PCIe Gen2 (5GT/s)

Table 17. Processor







Feature

Specification





Types

Intel Core i5 / i7 series

L3 cache

3 MB and 4MB

Table 18. Memory







Feature

Specification





Memory connector

Two SODIMM slots

Memory capacity

1 GB, 2 GB, 4 GB, or 8 GB

Memory type

DDR3L SDRAM (1600 MHz)

Minimum memory

2 GB

Maximum memory

16 GB

Table 19. Audio







Feature

Specification





Type

four-channel high-definition audio

Controller

Realtek ALC3226

Stereo conversion

24-bit (analog-to-digital and digital-to-analog)

Interface:
