3.MOWING AND MULCHING RECOMMENDATIONS
5.Install the bag support assembly on the left and right struts, while inserting the center strut pin in the the hitch plate hole.
6.Grasp the upper chute by the chute handle. Raise the upper and middle chutes, then slide the middle chute over the lower chute.
7.Install the grass bags, and secure the hopper top with its retaining band.
Cover Plate Reinstallationfor Mulching:
1.Remove the bagging kit in the reverse order of installation.
2.Install the cover plate, using the two 8 mm lock nuts. Refer to the illustration on page
10.Tighten the 8 mm nuts to a torque value of 15.2
(2.1 kg-m).
3.Install swirl guide B on the cover plate, using two 8 x 35 mm bolts, four 8 mm flat washers, and two 8 mm lock nuts, as shown. Tighten the 8 mm nuts and bolts to a torque value of 15.2
CHUTE HANDLE
LOWER CHUTE /
