Hard drive specifications
| ||||
|
|
|
|
|
Dimensions |
|
|
|
|
|
|
|
|
|
Height | 9.5 mm | 9.5 mm | 9.5 mm | 9.5 mm |
|
|
|
|
|
Width | 70 mm | 70 mm | 70 mm | 70 mm |
|
|
|
|
|
Weight | 101 g | 101 g | 101 g | 101 g |
|
|
|
|
|
Interface type | SATA | SATA | SATA | SATA |
|
|
|
|
|
Transfer rate | 100 MB/sec | 100 MB/sec | 100 MB/sec | 100 MB/sec |
|
|
|
|
|
Security | ATA security | ATA security | ATA security | ATA security |
|
|
|
| |
Seek times (typical read, including setting) |
|
|
| |
|
|
|
|
|
Single track | 3 ms | 3 ms | 3 ms | 3 ms |
|
|
|
|
|
Average | 13 ms | 13 ms | 13 ms | 13 ms |
|
|
|
|
|
Maximum | 24 ms | 24 ms | 24 ms | 24 ms |
|
|
|
|
|
Logical blocks | 1,048,576,000 | 625,141,400 | 488,397,168 | 312,560,640 |
|
|
|
|
|
Disc rotational speed | 7200 and 5400 rpm | 7200 rpm | 7200 and 5400 rpm | 7200 rpm and 5400 |
|
|
|
| rpm |
|
|
|
| |
Operating temperature |
| 5°C to 55°C (41°F to 131°F) |
| |
*1 GB = 1 billion bytes when referring to hard drive storage capacity. Actual accessible capacity is less. Actual drive specifications may differ slightly.
NOTE: Certain restrictions and exclusions apply. Contact technical support for details.
108 Chapter 6 Specifications
