Removal and replacement procedures

WLAN module

Description

Spare part number





Intel WiFi Link 5100 802.11 a/g/n WLAN module for use in Andorra, Antigua and Barbuda,

572507-001

Argentina, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Barbados, Belgium,



Bermuda, Bolivia, Bosnia, Brazil, Brunei, Bulgaria, Canada, the Cayman Islands, Chile, Colombia,



Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, the Dominican Republic, Ecuador,



Egypt, El Salvador, Estonia, Finland, France, French Guiana, Georgia, Germany, Ghana, Greece,



Guadeloupe, Guam, Guatemala, Haiti, Herzegovina, Honduras, Hong Kong, Hungary, Iceland,



India, Indonesia, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Japan, Jordan, Kenya, Kuwait,



Kyrgyzstan, Latvia, Lebanon, Liechtenstein, Lithuania, Luxembourg, Malawi, Malaysia, Malta,



Martinique, Mauritius, Mexico, Monaco, Montenegro, Morocco, the Nether Antilles, the Netherlands,



New Zealand, Nicaragua, Nigeria, Norway, Oman, Pakistan, Panama, Paraguay,



the People's Republic of China, Peru, the Philippines, Poland, Portugal, Puerto Rico, Qatar,



Romania, San Marino, Saudi Arabia, Senegal, Singapore, Slovakia, Slovenia, South Africa,



South Korea, Spain, Sri Lanka, Sweden, Switzerland, Taiwan, Tanzania, Thailand,



Trinidad and Tobago, Turkey, the United Arab Emirates, the United Kingdom, the United States,



Uruguay, the U.S. Virgin Islands, Venezuela, and Vietnam



Intel WiFi Link 5100 802.11 a/b/g WLAN module for use in Andorra, Antigua and Barbuda,

572508-001

Argentina, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Barbados, Belgium,



Bermuda, Bolivia, Bosnia, Brazil, Brunei, Bulgaria, Canada, the Cayman Islands, Chile, Colombia,



Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, the Dominican Republic, Ecuador,



Egypt, El Salvador, Estonia, Finland, France, French Guiana, Georgia, Germany, Ghana, Greece,



Guadeloupe, Guam, Guatemala, Haiti, Herzegovina, Honduras, Hong Kong, Hungary, Iceland,



India, Indonesia, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Japan, Jordan, Kenya, Kuwait,



Kyrgyzstan, Latvia, Lebanon, Liechtenstein, Lithuania, Luxembourg, Malawi, Malaysia, Malta,



Martinique, Mauritius, Mexico, Monaco, Montenegro, Morocco, the Nether Antilles, the Netherlands,



New Zealand, Nicaragua, Nigeria, Norway, Oman, Pakistan, Panama, Paraguay,



the People's Republic of China, Peru, the Philippines, Poland, Portugal, Puerto Rico, Qatar,



Romania, San Marino, Saudi Arabia, Senegal, Singapore, Slovakia, Slovenia, South Africa,



South Korea, Spain, Sri Lanka, Sweden, Switzerland, Taiwan, Tanzania, Thailand,



Trinidad and Tobago, Turkey, the United Arab Emirates, the United Kingdom, the United States,



Uruguay, the U.S. Virgin Islands, Venezuela, and Vietnam







Before removing the WLAN module, follow these steps:

1.Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

2.Disconnect all external devices connected to the computer.

3.Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and then unplugging the AC adapter from the computer.

4.Remove the battery (see “Battery” on page 4-7).

Maintenance and Service Guide

4–17
