JVC GR-FX50 SPECIFICATIONS

EN55

SPECIFICATIONS

Camcorder

General

Format : VHS PAL standard

Power source : DC 6.0 V

Power consumption

GR-FX50/FX40

light on : 8.1 W

light off : 5.2 W

GR-FX10 : 5.2 W

Signal system : PAL-type

Video recording system

Luminance : FM recording

Colour : Converted sub-carrier

direct recording

Conforms to VHS standard

Cassette : cassette

Tape speed

SP : 23.39 mm/sec.

LP : 11.70 mm/sec.

Recording time (max.)

SP : 60 minutes

LP : 120 minutes

(with EC-60 cassette)

Connectors

JLIP : ø3.5 mm, 4-pole, mini-head

jack

(compatible with RC-5325 plug)

Video : 1 Vp-p, 75 Ω unbalanced,

analogue output

(via Video output connector)

AC Power Adapter/Charger AA-V15EG

Power requirement : AC 110 V to 240 V`,

50/60 Hz

Power consumption :23 W

Output

Charge : DC 8.5 V , 1.3 A

VTR : DC 6.3 V , 1.8 A

Charging system : Constant current, peak

detection, timer controlled

Dimensions : 140 (W) x 42 (H) x 68 (D) mm

Weight : Approx. 300 g

Cassette Adapter C-P7U

Dimensions : 188 (W) x 25 (H) x 104 (D) mm

Weight : Approx. 240 g

Accessory : “R6 (AA)”-size battery x 1

Operating temperature

: 0°C to 40°C

Operating humidity :35% to 80%

Storage temperature : –20°C to 50°C

Weight

GR-FX50 : Approx. 720 g

GR-FX40 : Approx. 750 g

GR-FX10 : Approx. 740 g

Dimensions : 91 (W) x 119 (H) x 198 (D) mm

(with the viewfinder fully tilted

downward)

Pickup : 1/4” format CCD

Lens : F1.6, f = 3.9 to 62.4 mm, 16:1

power zoom lens with auto iris

and macro control, filter

diameter 40.5 mm

Viewfinder : Electronic viewfinder with

GR-FX40/FX10 : • 0.5” black/white CRT

GR-FX50 : • 0.55” colour LCD

White balance

adjustment : Auto/Manual adjustment

Audio : –8 dBs, 1 kΩ analogue output

(via Audio output connector)

Provided Accessories.................. Z pg. 3

Optional Accessories

•Battery Packs BN-V12U, BN-V20U, BN-V856U

•Car Battery Charger BH-V3E

•Compact VHS ( ) Cassettes EC-60/45/30

•Active Carrying Bag CB-V7U

•Remote Control Unit RM-V700U

Some accessories are not available in some areas. Please

consult your nearest JVC dealer for details on accessories

and their availability.

Specifications shown are for SP mode unless otherwise

indicated.

E & O.E. Design and specifications subject to change

without notice.
