How To Prepare the Machine For

Operation

How To Change or Rotate Brushes on Cylindrical Brush Head

To install or rotate brushes on the cylindrical brush head:

1.Raise the brush deck and turn the key switch “OFF”.

2.Raise the brush skirt and pull out to remove. See figure 11.

3.Remove thumb screw from brush door. See figure 12.

4.Lower door approximately 12 mm and slide door and hub assembly from brush. See figure 13.

5.Slide brush off hub at opposite end. See figure 14.

6.Rotate brush or replace.

7.Slide brush on drive hub and insert door and hub assembly into brush core.

8.Raise door and install thumb screw.

9.Place side skirt on retainer pins and lower in place.

10. Brushes should be rotated after every 20 hours of use.

Figure 11

Figure 12

Figure 13

Figure 14

Page -14-

CLARKE TECHNOLOGY Operator's Manual - SCRUBTEC R Manual Steering

Page 14
