How To Operate the Machine

How to Operate the Forward / Reverse Switch (see figure 28).

1.To go forward, push the up arrow side of the switch.

2.To go in reverse, push the down arrow side of the switch.

How to Fill the Solution Tank

The solution tank fill port is located at the left side of the machine (see figure 29). To fill the solution tank, follow this procedure:

1.Turn the key switch to the “OFF” position.

2.Remove lid.

3.Add a cleaning chemical to the solution tank. For the correct amount of chemical, follow the directions shown on the container. NOTE: Excess foam in the recovery tank could damage the vacuum motor, so use only the minimum amount of detergent necessary.

WARNING:

Always use low foam detergent. To



avoid the production of foam, before



starting to clean, put a minimum



quantity of antifoam liquid into the



recovery tank. NEVER USE PURE



ACID.

4.Fill the solution tank with clean water (see figure 29).

5.After filling the solution tank, replace the solution tank lid.

WARNING:

Water solutions or cleaning materials



used with this type of machine can



leave wet areas on the floor surface.



These areas can cause a dangerous



condition for the operator or other



persons. Always put CAUTION signs



near the area you are cleaning.

WARNING:

Machines can ignite flammable



materials and vapors. Do not use



with or near flammables such as



gasoline, grain dust, solvents and



thinners. Only use a cleaning



concentration recommended by the



chemical manufacturer.

WARNING:

ALTO recommends a maximum



water temperature of 120°F (49°C).

Operating the Machine

NOTE: Before scrubbing with the machine, become familiar with the operations and handling of the machine. Run the machine at the lowest traverse speed. Use the machine in an area that has no furniture or objects until you can do the following:

1.Traverse the machine in a straight direction, forward and backward.

2.Stop the machine safely.

3.Turn the machine both left and right and return to a straight direction.

4.Turn a 180o turn where one rear wheel just pivots.

Figure 28

Figure 29

CLARKE TECHNOLOGY Operator's Manual - SCRUBTEC R Manual Steering

Page -19-
