Nilfisk-ALTO R R R Final Assembly Parts List 10/06

CLARKE TECHNOLOGY Operator's Manual -
SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering
SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering
SCRUBTEC R Manual Steering Page -33-
CLARKE TECHNOLOGY
SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST
SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST
SCRUBTEC R 571, 586, 571 C, BOOST®®
®®
® R R
R R
R
Final Assembly Parts List 10/06
Qty Qty Qty.
Ref Part No. Description Rotary Cyl. Boost
1 pg 44-45 Tank, Recovery (Assembly) 1 - -
pg 44-45 Tank, Recovery (Assembly) - 1 1
2 pg 46-49 Tank, Solution (Assembly) - - 1
pg 46-49 Tank, Solution (Assembly) 1 1 -
3 pg 62 Plate, Electrical (28”) 1 - -
pg 62 Plate, Electrical (34”) 1 - -
pg 62 Plate, Electrical (Cyl.) - 1 -
pg 62 Plate, Electrical (Boost) - - 1
4 pg 34-35 Mainframe, Main Asm. (Rotary) 1 - -
pg 38-39 Mainframe, Main Asm. (Boost) - - 1
pg 36-37 Mainframe, Main Asm. (Cyl.) - 1 -
5 pg 42 Wheel, Front Steering 1 1 1
6 pg 61 Arm, Sec. Squeegee Lift 1 - -
7 pg 60 Squeegee, Secondary 1 - -
8 pg 52 Assembly, 28” Rotary Brush Head 1 - -
8pg 53 Assembly, 34” Rotary Brush Head 1 - -
8A pg 54-55 Assembly, 28” Cyl. Brush Head - 1 -
8B pg 56-57 Assembly, 32” Boost Head - - 1
9 10129L Assembly, Squeegee 32” 1 - -
910068L Assembly, Squeegee 41” 1 1 1
10 pg 43 Arm, Rear Squeegee Lift 1 1 1
11 40704A Pack, Battery 370 A.H. 1 1 1
12 53767A Pedal, Accelerator 1 1 1
13 pg 50-51 Column, Steering Asm. 1 1 1
14 70079A Plate, Warning 1 - 1
15 818381 Spring Extension 1 - -
NI 40895A Positive Cable 1 1 1
NI 40896A Negative Cable 1 1 1
NI 40882A Cable Fuse 1 1 1
NI 41217A Cable, Series 4 4 4
NI= Not illustrated
