Page 101

CLOCK

1 In the Main screen, select the <Applications> icon by using the Left/Right direction key of the Navigation button and press the ▶ button.

- The Application list appears.

2 Select <CLOCK> and press the ▶ button.

-The Clock screen appears displaying the current time.

3 Press the <MENU> button.

-To set the time, select <Clock Setting> and set the time by using the ◀/▶/▲/▼buttons.

-To exit the clock, select <Quit>.

101
