Page 158

6-64 Power Saving Function

This product provides a power saving function that automatically turns the screen off when the product is not used for a predetermined period of time to reduce power consumption. If the product enters power saving mode, the power LED turns to a different color to indicate that the product is in power saving mode.

When the product is in power saving mode, the power is not turned off and you can turn the screen on again by pressing any key or clicking the mouse. However, the power saving function only works when the product is connected to a computer that provides the power saving function.

STATE	NORMAL OPERATION	POWER SAVING MODE	POWER OFF

Power Indicator	On	Blinking	Off

Power Consumption	22 W	Less than	Less than
Power Consumption	22 W	0.3 watts	0.3 watts
		0.3 watts	0.3 watts

If there is no power cut-off switch, the power consumption is "0" only when the power cord is disconnected.

6-64	More Information

Page 158
