Instructions for the user
12.4 Removing the glass panels
The glass in the door should always be kept thoroughly clean. For easier cleaning, the door glazing can be fully removed by proceeding as described below. After opening the door and locking it in place as described in point “12.2 Removing the door”, remove the internal glass pane levering it as illustrated in figure 1, and detach the 4 pins that fix the glass to the door. If your oven also has a middle glass pane (figure 2) this can be extracted simply by lifting it upwards. After having carried out the cleaning, first of all replace the middle glass panel (if your oven has one), and then position the internal glass hinging it, as shown in figure 3, on the grooves of the oven door (see part A in figure 3). When the glazing has been positioned on the door, exert a slight pressure on the four fixing pins. If the door should close during these operations, simply relock one of the hinges as described in point “12.2 Removing the door”. The panes of glass can now be washed separately.
39
