Appendix 8

Lamp unit replacement and care (continued)

How to replace the lamp unit (continued)

6.Carefully insert the new lamp unit straight into the TV until it is fully seated.

Note :

Ć 1HYHUVXEMHFWWKHODPSXQLWWRH[FHVVLYHVKRFN

Ć 1HYHUWRXFKWKHODPSXQLWJODVVRURWKHUZLVHJHWLWGLUW\

Doing so may affect the image quality and reduce the service life RIWKHODPS6HH³&OHDQLQJWKHODPSXQLWJODVV´EHORZ

CLEANING THE LAMP UNIT GLASS

If you accidentally touch the lamp unit glass or otherwise get it dirty, wipe it with a lint-free lens cleaning cloth (such as a cloth for cleaning camera lenses or eyeglasses).

&$87,21NEVER clean a hot lamp with any type of flammable liquid or aerosol cleaning agent.

Many ordinary cleaning agents (such as glass cleaners) contain chemicals that may be flammable at certain temperatures. If the lamp unit is not allowed to cool for at least one (1) hour, such chemicals may ignite.

7.Using a Slotted screwdriver, tighten the two lamp unit screws.

Note: Hand-tighten only. Do not use an electric screwdriver.

Lamp unit screws (Slotted screwdriver)

127( Make sure the lamp unit and screws are installed securely; otherwise, the TV may not

turn on and the lamp life may be shortened.

8.Reattach the lamp unit door, making sure to insert the hooks on the left side of the lamp unit door inside the opening in the TV cabinet.

Insert the hooks inside the TV cabinet opening.

Lamp unit door

9.Replace the screw and tighten using a Slotted screwdriver.

Screw

Lamp unit door

127( Make sure the lamp unit door is installed securely, otherwise, the TV may not

turn on.

10.Plug in the power cord and turn on the TV. After the initial warmup period (which may take several seconds for full picture brightness), the TV should operate normally. If any of the following conditions exist, turn off the TV, unplug the

SRZHUFRUGDQGUHSHDWVWHSVăWRHQVXUHWKDWWKHODPS unit and lamp unit door are installed correctly:

Ć1RSLFWXUHĆ'DUNSLFWXUHĆ79ZLOOQRWWXUQRQ

 ,IDIWHUUHSHDWLQJVWHSVăWKHSUREOHPVWLOOH[LVWV

Call Customer Service at 1-800-631-3811.

'LVSRVLQJRIWKHXVHGODPSXQLW

Ć 3ODFHWKHXVHGODPSXQLWLQWKHHPSW\ER[IURPWKHQHZXQLW Ć .HHSWKHODPSXQLWRXWRIUHDFKRIFKLOGUHQDQGSHWV

&$87,21Always handle the lamp unit with care.

The lamp unit in this TV was designed for safe replacement by consumers; however, if the lamp unit is subjected to intentional or accidental abuse (such as excessive mechanical abuse or handling by

children or pets), the unit may break, exposing sharp edges or pinch points.

Ć 'LVSRVHRIWKHXVHGODPSXQLWE\WKHDSSURYHGPHWKRGIRU your area.

127( The lamp unit contains mercury. Disposal of mercury may be regulated due to environmental

considerations. For disposal or recycling information, contact your local authorities or the Electronic Industries Alliance (www.eiae.org).

English

Copyright © 2006 TOSHIBA CORPORATION. All rights reserved.

33
