GROUP:COMMUNICATION SETTING PARAMETERS

LIQUID CRYSTAL DISPLAY

ITEM

PARAMETER



ADJUSTMENT

DISPLAY

FACTORY

PAGE



NO.

DESCRIPTION



RANGE

RESOLUTION

SETTING

NO.















RS232 BAUD RATE

260

set RS232 baud rate

0: 2400 baud

-

2

9-22







1: 4800 baud













2: 9600 baud























NUMBER OF DATA BITS

261

Number of data bits

0:

7 bits

-

0

9-22







1:

8 bits





















PARITY SETTING

262

Parity

0: Even parity

-

0

9-22







1: Odd parity























INVERTER ID NUMBER

263

Inverter number



0 - 255

-

0

9-22















COMMUNICATION

264

Communication selection

0: Off

-

0

9-23

SELECTION





1: RS485 board*













2: Tosline-F10,















DN board,















MB+ board,















RIO board**













3: Tosline-S20 **













4: 12-bit binary input















(option board)













5: BCD board















(0.1 Hz units)













6: BCD board















(1 Hz units)





















MASTER/SLAVE

265*

Master/follower selection

0: Follower

-

0

9-23

SELECTION





1: Master (follower















follows master















freq. command)













2: Master (output















frequency)







RS485 BAUD RATE

266*

RS485 baud rate

0: Normal mode

-

0

9-23







1: High speed mode





















TOSLINE-F10/S20

267**

TOSLINE-F10/TOSLINE-S20

0: Off

-

0

9-23

COMMAND INPUT



command input

1: Frequency















command













2: Command input













3: Frequency















command,















command input























Table continued on next page

*Items 265 - 266 are available only when Item 264 Adjustment Range option 1 is selected. **Item 267 is available only when Item 264 Adjustment Range option 2 or 3 is selected.

Cycle power after changing any parameter in GROUP: COMMUNICATION SETTING PARAMETERS.

Inspection

Specifications Precautions

Wiring

Jumpers

Panel

Keypad

Programming Parameters

Service

Dimensions

Index

8 - 24

Page 59
