TOSHIBA

GROUP:UTILITY PARAMETERS (cont'd)

LIQUID CRYSTAL DISPLAY

ITEM

PARAMETER



ADJUSTMENT

DISPLAY

FACTORY

PAGE



NO.

DESCRIPTION



RANGE

RESOLUTION

SETTING

NO.

















PASS NUMBER

284

Panel operation mode selection



0 - 99

-

0

9-26















CPU VERSION

285

CPU version

Can be monitored only

-

120

9-26















ROM VERSION

286

ROM version

Can be monitored only

-

6800

9-26















EEPROM VERSION

287

EEPROM version

Can be monitored only

-

100

9-26















INVERTER TYPEFORM

288

Inverter typeform

Can be monitored only

-

-

9-26















STATUS MONITOR #1

289

Programmable monitor #1

1: post-compensation

-

2

9-27

DISPLAY SELECT



(displayed in MON mode)



output frequency













2: frequency















command setting













3: output current













4: input voltage













5: output voltage













6: torque current













7: excitation current













8: PID feedback value













9: motor overload















ratio













10:inverter overload















ratio













11:DBR overload ratio













12:input power













13:output power













14:RR input value













15:peak load current













16:peak input voltage





















STATUS MONITOR #2

290

Programmable monitor #2

Same options as

-

3

9-27

DISPLAY SELECT



(displayed in MON mode)

Item 289





















STATUS MONITOR #3

291

Programmable monitor #3

Same options as

-

4

9-27

DISPLAY SELECT



(displayed in MON mode)

Item 289





















STATUS MONITOR #4

292

Programmable monitor #4

Same options as



5

9-27

DISPLAY SELECT



(displayed in MON mode)

Item 289























FREQUENCY UNITS

293

multiplier to scale Hz display



0 (Off), 0.01 - 200

0.01

0.00

9-27

SCALE FACTOR































FREQUENCY DISPLAY

294

Frequency display resolution

0:

1 Hz

-

1

9-27

RESOLUTION





1:

0.1 Hz













2:

0.01 Hz























ACC/DEC TIME UNITS

295

ACC/DEC time units selection

0:

0.1 secs

-

0

9-27

SELECTION





1:

0.01 secs























CURRENT UNITS

296

Current units selection

0:

%

-

0

9-27

SELECTION





1:

A























VOLTAGE UNITS

297

Voltage units selection

0:

%

-

1

9-27

SELECTION





1:

V























Table continued on next page

Inspection

Specifications Precautions

Wiring

Jumpers

Panel

Keypad

Programming Parameters

Service

Dimensions

Index

8 - 30
