Mobile Module (LPM)

Boards & MORE !

Deciding between making or buying?

Reduce outsourcing risks

Minimize potential problems

Stay in control

with Kontron First-Class Outsourcing Management

DIMM-PC

������

������

Modules & MORE!

So, you are convinced that a Kontron Computer-On-Module

meets your product requirements but you don’t know how

to go about getting a customized baseboard?

We support the full range of

Kontron Computer-On-Modules

DIMM-PC

X-board

E2Brain

ETX

ETXexpress

Boards & MORE!

You are looking for a fully customized computer board?

Custom LPM Application

Mobile Module (LPM)

Designed to be compatible with Intel’s® MMC2 module, the Kontron low power modules for applied computing achieve high performance in embedded applications.

The 500 MHz Intel® Pentium® III processor based module extends the lifecycle of your existing designs.

With the 700 MHz Intel® Pentium® III processor based module, Kontron’s module leverages your design to extend the performance of your system as a low power envelope. In most applications, Kontron’s modules enable customers to improve the performance of their system without redesigning it.

X-

ETX (microSERVER)

ETX baseboard

E2Brain

We have the right solution for you

Take advantage of our engineering expertise and get your

whole solution from Kontron. We offer design and

production services for your customized baseboard – COM

or full custom solution that are tailored to your needs.

Specification optimization & consulting for

competitively priced products

Design and Production to ensure high product quality

SW & BIOS services to make your solution work

Lifecycle management to make your investment

pay off

We offer First-Class Project Management

Our customer focused Outsourcing Project Management

allows you to concentrate on your core business:

You are in full control of your outsourcing project – our

design process combines flexibility even in the design

Mobile Module (LPM)

Features

LPM500

LPM700

LPM700 /850

CPU

Low power Pentium® III 500 MHz

Low power Pentium® III 700 MHz

Low power Pentium® III 700 MHz

Cache

256 kByte

256 kByte

256 kByte

Chipset

Intel® BX

Intel® BX

Intel® BX

Interface

MMC2-Style (Memory, PCI, AGP)

MMC2-Style (Memory, PCI, AGP)

MMC2-Style (Memory, PCI, AGP)

Dimensions H x W x D

2.5 x 4 x 0.39"

2.5 x 4 x 0.39"

2.5 x 4 x 0.39"



(63.5 x 101.6 x 9.9 mm)

(63.5 x 101.6 x 9.9 mm)

(63.5 x 101.6 x 9.9 mm)

RoHS compliant

*) Intel® GX chipset available on request

24

ETXexpress-PM

phase with design quality control through regular

reviews and customer approvals.

Our support doesn‘t stop with your product approval –

we will support and stay with you throughout the

lifetime of your solution.

RELAX AND BUY! Give us a try!

We`d like to add YOU to our track record of successful outsourcing projects.

25
