ThinkIO - I’ve got it all!

The ThinkIO is the combination of a complete PC (Intel® Pen-

Memory

tium® MMX compatible 266 MHz processor) with the granular

Bootable Onboard Flash Disk:

WAGO-IO/-SYSTEM 750 and 753. The combination of the per-

32/128 MByte

fect connectivity and diversity of the Wago clamps with this

SDRAM: 32 MByte/128 MByte

DIN Rail PC provides the opportunity to realize new ideas.

RAM: 128 kByte, battery-buffered



External Compact Flash type I/II

The optional IEC 61131-3 compliant PLC Programming System



CoDeSys provides the customer with an easy way to configure

Flexible Field Bus Selection:

the ThinkIO.

PROFIBUS-DP Master/Slave



CANopen Master/Slave



DeviceNet Master/Slave



Dimensions: 160 x 70 x 95 mm



Available Software



PLC Programming System CoDeSys



with Target Visualization



Linux 2.4 GPL BSP



Windows CE 5.0 BSP



OPC Driver



SOPH.I.A.



Delivered Devices are ready to use



with pre-installed software.

With features like USB, Ethernet, RS232, DVI and external watchdogs in combination with field buses like PROFIBUS-DP, CANopen and DeviceNet, the ThinkIO offers an extraordinary connectivity.

System IO

2 Digital Input and Output Channels each opto-isolated 2x USB 1.1 Ports

1x RS232 Serial Port

2x 10Base-T/100BASE-TX Fast Ethernet ports

1x DVI panel-link, TFT, VGA (with adapter) External Watchdog

Run/Stop Switch Reset Button

System Processor

Geode™ SC1200 (266 MHz) and integrated Chipset from AMD Cache: 16 kByte 1st level

The WAGO-I/O-SYSTEM 750 and 753 are the smallest modularized, fieldbus independent, input/output sys- tems for decentralized automation. They facilitate the integration of cost and space saving I/O clamp nodes using application specific, intermixable, digital, analog and complex input/output modules.

The WAGO I/O System 753 offers all existing clamps with the additional advantage that it separates the clamps’ wire and function blocks

Fine Granularity: 1, 2, 4 or 8 channels in one bus-module

Safe Investment: fieldbus independent node design

Special Functions: different voltages, output power, and signals on one clamp

Furthermore, I/O clamps are available for Ex zone, Profisafe, step motors, Dali bus, valves and others

Safe Operation: Certification for industrial auto- mation, construction, shipboard automation and on/off shore applications guarantees a wide range of application possibilities (CE and GL approval)

ThinkIO and HMI

It is possible to connect Panels and Touchpanels directly to the ThinkIO via the DVI and USB interfaces. We suggest the 6.4" (640x480), 8.4" (640x480) and 10.4" (800x600) panels on page 81. The ready-to-use configuration means that with our displays, commu- nication between ThinkIO and the display can start immediately.

For visualization of a process, the Target

Visualization is implemented in CoDeSys.

Long distances between ThinkIO and Touchpanel on the machine can be solved by the Long Distance Monitor System. Up to 40 m can be bridged with this system (details see page 82).

DIN Rail PC / ThinkIO

CoDeSys Automation Alliance CAA

More than 60 companies belong to the CoDeSys Automation Alliance. The aim of this association is to achieve a standard within the IEC 61131-3, which helps to harmonize programs used in automation on independent hardware from different suppliers.

CoDeSys is a multi-function software tool for the automation industry; it covers many typical tasks in the field of plant and machine construction. CoDeSys offers a range of open interfaces for external soft- ware systems.

CoDeSys supports all five IEC 61131-3 languages and on top offers a sixth editor, which is a variation of the Function Block Diagram (FBD), called Continuous Function Chart (CFC).

Integrated Target Visualization

Integrated Web Visualization

Integrated Modbus TCP/IP protocol

Field bus support and configuration for Profibus-DP, CANopen and DeviceNet

Open Interfaces: OPC, HTTP, TCP/IP

Network variables by symbolic access via TCP or CAN

Tracing, logging, parameterizing watchdog properties

Offline simulation

Touch Panels, TFT Monitors

p. 80 f

Industrial Software, OPC drivers

p. 92 ff
