4U Rackmount Systems

KPR - PxV414 and KPR - MBx406 Premium 4U Systems

4U Rackmount Systems

VL406 and VL414 Value 4U Systems

KPR, Kontron’s Premium 4U system, is the answer if you need long term availability. KPR has the longest life- cycle of any Rackmount system on the market. The KPR utilizes a revolutionary housing innovation, E-PAC (Electronic Packaging Assembly Concept). The housing features a chassis with a molded-foam lining designed to hold all major components securely in place. All com- ponents such as the hard disk, boards and fans are installed in a secure foampacked frame. Resistance to vibration and shock is considerably improved by embed- ding the computer’s inner workings in foam.

4U Rackmount Systems

As a result the computer has a longer life span, is easier to maintain and has an improved MTBF. With KPR you buy 16 years of experience.

E-PAC

Particle foam

Pure hydrocarbon

High energy absorption relative to weight

Tolerant of water, dust & chemicals

Tolerant of high tempe

Resumes original shape after distortion

If you do not need the highest industrial tolerances, Kontron 4U Value Line is the best choice. With state of the art performance and an impressive feature set, the Kontron Value Line is the budget solution.

*) Without FANs

Features	KPR - PxV414 PCI 951	KPR - PxV414 PCI 955	KPR - MBx406 886 LCD	KPR - MBx406 889 LCD
Construction		Anti-corrosion heavy duty steel EN 10215-DX 51D+AZ 150-A-C
Mounting		19" (Rackmount)
Paint Color		Front: RAL 7021 (black)
Weight	~17 kg	~17 kg	~16 kg	~16 kg
Control Panel Indicators		Power LED, HDD LED
Control Panel Switch		PWR ON, Reset
CPU	Celeron® 2.0 GHz,	Celeron® M 1.3 GHz,	Celeron® 2.0 GHz,	Celeron® 3.0 Prescott,
	Pentium® 4 2.4 GHz,	Pentium® M 1.8 GHz	Pentium® 4 2.4 GHz,	Pentium® 4 3.2 GHz Prescott,
	Pentium® 4 2.8 GHz		Pentium® 4 2.8 GHz	Pentium® 4 3.4 GHz Prescott
Front Side Bus	400/533 MHz	400/533 MHz	400/533 MHz	533/800 MHz
DRAM	Up to 2 GByte DDR 333	Up to 2 GByte DDR2	Up to 2 GByte DDR 333	Up to 4 GByte DDR2
I/O Standard	2x USB	2x USB	2x USB	2x USB
Drives		1x 3.5" internal, 1x 3.5" and 2x 5.25" front accessible
Expansion Slots	Backplane 1: 5x ISA, 2x PICMG, 4x PCI, 3x PCI half size,		6x PCI, 1x AGP x4	4x PCI 32, 1x PCI express
	Backplane 2: 7x PCI*, 3x PCI half size, 2x PICMG, 2x ISA			x 16, 2x PCI Express x 1
Power Supply		AC 300 W wide range
Cooling		2 Chassis FAN
Protection Class		IP54 front
Options		I/O boards, Fieldbus, Ethernet cards, sound cards, fan control board
(Fully Certified with System)
Altitude		10000 ft
Vibration DIN EN 60068-2-6		10 - 58 Hz +-0,075 mm, 58 - 500 Hz 1 g
Rel. Humidity		10 - 95% non condensing
Operating System	WIN 2000, WIN XP, Linux,		WIN 2000, WIN XP, Linux,
	Solaris with PCI 951
MTBF		> 30000 h*
Dimensions H x W x D		Front: 19" x 4U, Body: 174 mm x 446 mm x 452 mm
Operating Temperature		0° to 50°C	0° to 45°C
Type		Premium
RoHS compliant			-	

70

V	855 GME	VL406 889LCD ATX	VL414 PCI951
		Heavy duty steel
		19" (Rackmount), Desktop
		Black Chassis and Front
		15 kg	16 kg
		Power LED, HDD LED
		PWR ON, Reset
Celeron® M 1.3 GHz,		Celeron® 3.0 Prescott,	Celeron® 2.0 GHz, Pentium® 4
Pentium® M 1.6 GHz		Pentium® 4 3.2 GHz Prescott	2.4 GHz, Pentium® 4 2.8 GHz
400 MHz		533/800 MHz	400/533 MHz
Up to 2 GByte DDR		Up to 4 GByte DDR2	Up to 2 GByte DDR
		DIN Keyb
		1x 3.5" internal, 1x 3.5" and 3x 5.25" front accessible
6x PCI 32 bit, 1x AGP		4x PCI 32 bit, 2x Express x1,	Backplane 1: 5x ISA,
		1x PCI Express x16	2x PICMG, 4x PCI, 3x PCI half size,
			Backplane 2: 6x PC*, 3x PCI half
			size, 2x PICMG, 2x ISA

AC 300 W front

2 FANs

IP 20

I/O boards, Fieldbus, Ethernetcards, Soundcards, Slide Rails

basic industrial grade

10 - 58 Hz +-0,075 mm, 58 - 500 Hz 1 g

10 - 80% non condensing WIN 2000, WIN XP, Linux,

		> 25.000h*
FANs		Front: 19" x 4 U, Body: 173 mm x 348 mm x 450 mm
		0° to 45°C	Touch Panels, TFT Monitors	p. 80f
Without
		Value	Industrial Software, OPC drivers
				p. 92 ff
*)			
