Intel Ethernet Switch Boards  JRex SBC,  JRex Value Line,  JRex Embedded Line Expansions Jflex

Page 15

JRex SBC 3.5"

Complete Systems

p. 60 f

JRex SBC 3.5"

The JRex family feature The following interfaces stay the same - throughout the whole JRex embedded line FAMILY!

Internal connectors

Kbd./Mouse

LAN

USB

VGA/LCD

COM1

External connectors

JRex Embedded Line Expansions: JFLEX

JFLEX System connectors

IDE

LPT

FDC

Compact Flash

JFLEX

Reduce



System



Costs!

new



JRex SBC 3.5"

Features

JRex-GX1

JRex-C3/P3

JRex-VE/VC

JRex-CE

Line







Embedded Line



CPU

AMD Geode® GX1

ULP Intel® Celeron®,

VIA Eden®, VIA C3®

Intel® LV/ULV Celeron®





LP Intel® Pentium® III





CPU Clock

300 MHz

300

MHz/700 MHz

300/600/1000 MHz

400/733 MHz

Front Side Bus

66 MHz

100

MHz

133 MHz

100/133 MHz

JRex-PM

Intel® Pentium® M, Celeron® M

600 MHz up to 1.8 GHz

400 MHz

JFLEX-miniPCI

JFLEX-Communication1

JFLEX-SERIALGPIO1

miniPCI socket,

2x LAN, 2x USB, Firewire,

4x COM, 4x 8 Bit GPIO, LPT2,

RoHS compliant

RoHS compliant

CANBus-option, RoHS compliant









JFLEX-Sound1

JFLEX-Multimedia1

JFLEX-PCMCIA1

line-in, line-out, mic-in (jackplugs)

DVI or TV OUT, sound (AC97, SPDIF),

PCMCIA drive for WLAN and hot swap

AC97-sound, RoHS compliant

Firewire, RoHS compliant

mass storage, RoHS compliant













new

JFLEX-3COMGPIOPCcard-USB

JFLEX-4COMGPIOPCcard

3x COM, 2x USB, 4x 8 Bit GPIO, 32 Bit PCMCIA drive bay,

4x COM, 4x 8 Bit GPIO, 32 Bit PCMCIA drive bay,

RoHS compliant

RoHS compliant

JRex Value Line

JRex-GX1LCD

JRex-786LCD

AMD GeodeGX1 300 MHz

Socket 370 Pentium® III/Celeron®

PC/104 und PC/104-Plus, LAN, USB, CRT/LCD

PC/104-Plus only, LAN, USB, CRT/LCD

Cache

L1: 16 kByte

L2: 128/256 kByte

L2: 64 kByte

L2: 256 KByte

BIOS





Phoenix



Chipset

CS5530A

VIA® Twister® T

VIA® Twister® T

Intel® 815 / ICH4

DRAM

256 MByte

512 MByte

512 MByte

512 MByte SDRAM

DRAM socket

DRAM-DIMM

SDRAM-DIMM

SDRAM-DIMM

SDRAM-DIMM

CompactFlash

Audio





AC97



Hard Disk

EIDE

EIDE (UDMA-66)

EIDE (UMDA-100)

EIDE (UMDA-100)

USB

2x

2x

2x

2x USB 2.0

Ethernet

1

1

1

1

Graphics Controller

on chip



S3 Savage

Intel® Graphics

Graphics Memory

up to 4 MByte

up to 32 MByte

up to 32 MByte

12 MByte VRAM

Graphics





CRT/LCD, JILI-interface



IEEE 1394 Firewire





via JFLEX®



Serial Channels





1x, expandable via JFLEX®



Drives





2x 1.44/2.88



Watchdog

System Monitoring

Expansion





JFLEX®



Special Features

low power

-

300/600 MHz FANLESS for

4x GPIO and 2nd COM onboard







rugged use



Power Management

APM 1.2

APM 1.2 / ACPI 1.0

APM 1.2 / ACPI 1.0

APM 1.2/ ACPI 2.0

Cooling

Passive

300 MHz Passive /

300/600 MHz Passive/

400 MHz Passive /





700 MHz Active

1000 MHz Active

733 MHz Active

Dimensions H x W





102 x 147 mm



I/O Expansion Type





JFLEX®



Operating Temperature





0 to 60°C



RoHS compliant

-

-

L2: up to 2 MByte

Intel® 855GM / ICH4

1 GByte DDR

DDR-RAM-DIMM ECC

EIDE (UMDA-133)

2x USB 2.0

1

Intel® Extreme Graphics 2 up to 2x 32 MByte

DUAL Independent panel & Enhanced SpeedStep

APM 1.2/ ACPI 2.0 Active

28

29
