Sun Microsystems Interface Adapter manual External Cabling

Page 26

Note – Refer to your system installation guide or service manual for detailed instructions for the following steps.

1.Power off your system, using the standard shutdown procedures described in the Solaris Handbook for Sun Peripherals or your system service manual.

The Solaris Handbook for Sun Peripherals is shipped with the Solaris OS software and is available on the http://docs.sun.com web site.

2.Remove the cover from the unit to access the card slots and connectors.

3.Select an available 3.3 Volt or 5 Volt PCI slot and remove the slot filler panel.

4.Insert the adapter into the PCI connector of the system unit.

Ensure that the front plate on the adapter mounts flush with the chassis panel opening.

5.Install the front plate screw to secure the adapter into the chassis. This also provides a chassis ground connection to the adapter.

6.Reinstall the cover on the unit.

7.Attach the serial port cable assembly to the I/O connector on the adapter.

8.Connect any cables from the peripheral devices to the RS-449 connectors on the adapter’s cable.

9.Turn power back on and allow the system to reboot.

This completes the hardware installation. Proceed to “SunHSI PCI Software Installation” on page 9.

External Cabling

The SunHSI/U adapter provides external connectivity through a passive cabling system. A hydra-style connector provides connectivity to four RS-449 devices by means of four DB-37 female connectors in a DTE configuration.

Note – Always use shielded twisted pair RS-449 cables with your SunHSI/U adapter.

6 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • December 2005
