3M MPro110 NK03-S005 Rechargeable Lithium-Ion Battery, Supported Computer Signals, Description

Page 15

3M™ Micro Professional Projector MPro110

NK03-S005 Rechargeable Lithium-Ion Battery

Description	Specification
Type	Rechargeable Lithium-ion Battery
Rated Capacity	3.7 V/ 1050mAh
Dimensions	40.4 x 34.4 x 9.4 mm (1.6” x 1.4” x 0.4”)

Do not throw battery into trash. Please dispose of according to federal, state, or local laws

Supported Computer Signals

Description	Resolution (width x height)	Refresh Rate
VGA	640 x 480	60 Hz
SVGA	800 x 600	60 Hz
XGA	1024 x 768	60 Hz
WXGA	1280 x 768	60 Hz

Replacement Parts / Accessories

	Description	3M Part Number
	US AC Power Adapter	78-6969-9972-7
	EU AC Power Adapter	78-6969-9977-6
	UK AC Power Adapter	78-6969-9995-8
	Rechargeable Battery	78-6969-9974-3
	AV Cable Kit	78-6969-9979-2
	( Video Cable and RCA Adapter)	78-6969-9979-2
	( Video Cable and RCA Adapter)
	VGA Cable	78-6969-9978-4

Operator’s Guide

© 2008 3M. All Rights Reserved.

15
